X-ray counting machine supporting work order management and data query

X-ray Counting Machine Supporting Work Order Management and Data Query

Working Principle

Key Advantages

Closed type X-ray tube for the longest lifetime and maintenance-free operation
17" Super definition digital flat panel detector (FPD)
Counting four 7" reels or one 15" reel in 7-10 seconds
Permanently updated AI deep learning algorithm with free updates
Integration with MES, ERP, WMS, and other management systems
Simultaneous automatic code scanning and label printing
No need to switch single/multi reel counting mode
Easy to operation, only 2 hours to training

Equipment Specifications

X-ray Source	80kV (optional), 700μA, 30μm focal spot
Detector	430×430mm, 3072×3072, 139μm pixel
Counting	Min: 01005 \| Speed: 7-10s \| Accuracy: ≥99.98%
Mechanical	1000×1300×1820mm \| 580kg \| 800W max
Safety	Radiation ≤1μSv/h \| safety interlock \| anti-pinch \| emergency stop

AI Deep Learning Algorithm

As counting operations increase, the system becomes progressively more accurate. The algorithm efficiently handles similar components and larger trays with improved performance over time.

Cloud Database Integration

This continuous improvement process ensures counting accuracy approaches 100% over time, with expanding component type coverage. When encountering new components, the system can directly access stored data for enhanced efficiency, accuracy, and coverage.

Speed & Accuracy Performance

Reel Size	Parts Size	Quantity	Accuracy	Speed
7" (180mm)	01005	40000	99.98%	9-10s
7" (180mm)	0201	20000	99.99%	8-9s
7" (180mm)	0402	10000	99.99%	7-8s
7" (180mm)	0603	5000	99.99%	7-8s
10" (254mm)	1206	5000	99.99%	7-8s
15" (380mm)	1206	10000	99.99%	7-8s

Sample Images

XC-01 component counter sample image showing high-precision counting results

XC-01 component counter sample image showing various component sizes

XC-01 component counter sample image showing reel counting process

XC-01 component counter sample image showing final counting accuracy
