| Brand Name : | WELLMAN |
| Model Number : | RS-1000 |
| Certification : | CE FDA |
| Payment Terms : | T/T |
1.Introduction of advantages
Simple to operate
New staff even can do better than skilled staff after 10 mins
operation, reduce machine stop time, improve efficiency.
Save manpower:
One person can be responsible for two SMT lines. (Base on customer
actual lines)
Empty material position and spacing determination:
use CCD optics to automatically detect whether materials, and
automatically and accurately calibrate the material cut position
Material belt recovery:
Operator can press recycling button to achieve automatic recycle
after successful connection.
Accurate and efficient:
It takes only 10 seconds to finish each connection, pass rate 98%.
Equipment passing probability:
the machine passing rate at the feeding point reaches more than 98%
Error prevention system:
Scanning material barcode to prevent errors.(Match the customer‘s
anti-error system)
2.Specification parameters
Equipment usage and application
This equipment can use for fast connection of automatic SMT lines without line stop.
Application
Paper type, adhesive type, width 8mm, thickness 0.25-1.3mm. 99% of the materials on the market can be used. (special materials need to be confirmed with us)
Equipment usage and application This equipment can use for fast connection of automatic SMT lines without line stop. Application Paper type, adhesive type, width 8mm, thickness 0.25-1.3mm. 99% of the materials on the market can be used. (special materials need to be confirmed with us)
overall dimensions | 550mm * 470mm * 1300mm (L * W * H) (including code scanning gun) |
work height | 890mm |
Material connection cycle | 10s (automatic material collection time and empty material detection time, excluding upper and lower materials) |
connection precision | 0.08MM |
Auxiliary function (optional) | Add the expansion material caliper to meet the manual connection of 12MM-88MM materials |
source | The 18650 battery pack DC 36V was used |
operate time | Full power state of 12-14H |
charge power supply | 220V 50Hz |
Low voltage alarm | Bring in a low-voltage reminder function |
Empty material level, material spacing identification | Empty material position detection function and spacing are automatically determined; black plastic belt opaque spacing should be determined manually |
camera | Left, right 130W pixel camera |
illuminant | LED White light source |
Per pass rate | ≥97％ |
mechanicalness noise | 50 decibel |
power rating | 150W |
Vacuum pressure | -20Kpa |
Volume collection function of material belt | Button controls automatic feeding |
Material auxiliary material | 1500 sheets (metal or tape) |
operating system | Industrial PC + 10.1-inch touch display, WIN10 OS |
attended mode | With your own WIFI or network port communication |
Barcode recognition ability | Adopt wireless scanning gun, support 1D code, 2D code |
work height | Bring the material barcode scanning alignment and error prevention (can be connected according to the customer error prevention system, this is the purchase item) |
weight | 62KG (excluding battery) |
3.SStructure is introduced
4.Introduction to spindle structure
5.Introduction of rail transfer structure
6.Introduction of the operation interface
7.Feed receiving effect
8.Time comparison between automatic feeder and manual connection
9.Software advantages
10.Effect comparison between automatic feeder and manual connection
|
|
